Medical Device Battery & Medical Equipment Battery Pack

Lithium Battery for Healthcare & Medical Devices

Gushine offers custom medical device battery packs for high-reliability applications, from portable ultrasound machines, portable patient monitors, and home oxygen concentrators to AED and glucometers.

With over 10 years of experience in servicing the medical industry, Gushine has been dedicated to offering tailored medical equipment battery pack solutions for a wide range of medical devices and applications. Our lithium-ion battery pack features advanced safety circuits, balancing circuits, and a built-in BMS to ensure safety, consistency, and long-term reliability. We manufacture all medical equipment battery packs in facilities certified to ISO 13485, ensuring the highest standards of quality and compliance.

Custom Lithium Battery Pack for Medical Devices

Industry Applications

Portable Ultrasound Machine

Portable Patient Monitor

Home Oxygen Concentrator

Infusion Pump

AED

Blood Pressure Monitor

Glucometer

Medical Device Battery Solutions

NTC Sensor

Temperature monitoring, over-temperature protection, fault diagnosis, optimizing charging and discharging process

Engineering Plastic Shell

Flame retardant (UL94-V0) with added AG antimicrobial silver ions

Plastic Ultrasonic Welding

Achieves IP67/IP68 waterproof and dustproof rating

BMS

Smart monitoring and management; fault alarm and pre-warning

Battery Pack

18650/4S2P

Featured Models

18V 2500mAh Medical device lithium battery pack

Model: YR001B-5S1P
Rated Capacity: 2500mAh
Nominal Voltage: 18V
Charge Current: 1A (standard), 3A (max)
Discharge Current: 1.25A (standard), 18A (max)
Dimensions: 78.5(L) x 53.6(W) x 40.1(T) mm
Waterproof rating: IPX5
Application: Mobile X-ray scanner

3.85V 4000mAh Medical device lithium battery pack

Model: MZ573Li
Cell: NCA596080 / 3950mAh / 3.6V
Minimum Capacity: 3950mAh
Nominal Voltage: 3.6V
Dimensions: 210(L) x 115(W) x 7.55(T) mm
Application: Smart medical tablet detector

14.4V 6500mAh Medical device lithium battery pack

Model: XS001B-RBA-4S2P
Rated Capacity: 6500mAh
Nominal Voltage: 14.4V
Charge Current: 1.3A (standard), 3.25A (max)
Discharge Current: 1.3A (standard), 10A (max)
Dimensions: 203(L) x 62.5(W) x 25.5(T) mm
Application: Portable ultrasound machine

Solution Overview

Featured Batteries

Items	Details
Battery Cell	18650/21700, Lipo battery cells, Prismatic cells
Configuration	1S-4S
Capacity	2000mAh-10000mAh
Voltage	3.7-14.8V
Temperature	Charge: 0℃ to 45℃ Discharge: -20℃ to 60℃
Protection	Shock-resistant, waterproof, temperature protection, fire-retardant casing, antibacterial protection
BMS	Heat dissipation design, protection circuit, balanced charging, fault diagnosis and protection, communication (I²C，，，，，，，SMBus)
